Lately I’ve been so uninspired by my pictures from the kitchen. I take a photo (almost) every day of Kiddo1′s lunch so I can post it in order to motivate me to make good lunches with a variety of foods. It’s hard to get a good shot in my kitchen because there isn’t a lot of natural light in there. And now heading into winter, there isn’t any natural light when I’m actually packing lunch so I need a little brightening up.
Thank goodness I found this tutorial for making a photography soft light from The Tip Toe Fairy. I highly recommend reading her tutorial first since that is what I used to make my own light. The only difference with me is that I’m super cheap, so I even made my own box for the light (The Tip Toe Fairy uses a lamp shade). Therefore, I wanted to share how I made the box and everything just in case you’re as thrifty as me.
DIY Photography Soft Lights
Here’s what you need:
Cardboard – enough for four 8-1/2″ x 11″ pieces plus one 6″ x 6″ piece
Piece of letter-sized paper for making a template
8-1/2″ clamp light, it looks like this and you should be able to find it at most hardware stores:
Also a good quality light bulb (I got a LED bulb that’s equivalent to 100w, but it cost twice as much as the clamp light! It also has a warm light and I’d rather go for something a lot more cool next time.
And a scrap of clean white fabric that’s at least 13″ x 13″
Here’s what you do:
First, make a template from the letter-sized piece of paper (that’s a regular 8-1/2 x 11 piece) Use scrap paper cause this isn’t going to be part of the finished product.
Just take the piece of paper and fold it in half “hamburger style.” The grab the outside corner and fold it back at an angle like this:
Once the two sides are folded at the same angle, unfold the middle of the paper so it looks like the above picture. Now you have a template to make four identical sides for the light box.
I found a cardboard box in the garage that I could use to make the light box. I just traced the template on all four sides of the box and cut them out.
Then it was time to glue.
I put one of the box sides on the counter and ran a line of glue near the edge, the stood another box piece on its side. I used a mason jar to support the box piece so I didn’t have to stand there with it.
I did this for two pair of sides:
Then ran off to play with the kids for awhile. The glue needs to dry so just leave it in a place where it won’t be disturbed. If you have children and pets, check every now and then to make sure no one has disrupted the creation. I left mine for about an hour.
Once the pairs were ready, it was time to combine them, like so:
More mason jars in action. The box will want to tip until the glue sets, so support the sides like this again and run off to play with kids. Or clean something if you want.
Once the glue was set I used duct tape to reinforce the connections, just in case. Just a little bit of duct tape like in the above photo.
Next it was time to make a piece of cardboard to seal up the back end of the box. I just tipped the light box over (once the glue was dry, of course) so the more narrow opening was down on a piece of cardboard. I traced around the light box so I had a nice square to cut out.
Then you need a hole in the center so the clamp light can go through. To make the whole, I just found the mid-point of the cardboard square, then guessed at the hole size. This is not exact science. Unless you don’t have any more spare cardboard. If you don’t, you might want to do a little measuring so you don’t waste your piece.
The end cap should look like this. I’ve also already added the lines of glue needed to secure the end cap to the light box.
See how my pictures are turning out blurry with the crappy light in my kitchen? Maddening. I made the hole in my piece a little big so I just used some masking tape to make it slightly smaller.
To know how big the hole should be, you’ve got to take apart your clamp light. The big aluminum shade screws off the light ballast. The black ballast (the part that holds the light bulb) is what needs to go through the hole. You don’t have to remove the clamp – that will be on the outside of the box anyway. There’s a picture coming up of the ballast secured in the box top, but for now we just want to make sure the ballast will fit in there.
Anyway, now stand the light box up on the end cap to set the glue, like this:
One last time… take off while the glue dries. Give it 30 minutes at least.
Once the glue is dry, do some more duct tape reinforcement between the box top and the sides. I add the tape on the inside and outside of the box.
Now the inside needs to be covered in aluminum foil so the light bounces around a bunch in the box. I used that same paper template from making the box sides to fold the aluminum foil before trying to secure it to the sides. It made it so much easier! Just lay the template down on the foil and fold:
Now you can just slide the aluminum foil in the box without too much of a struggle. Once you’ve got a piece in place, pull it back a little and use some folded-over tape (homemade double-sided tape) to secure the aluminum foil down. You can also skip that and just tape the edges of the foil onto to inside of the lid. Also fold the foil over the outside edge and tape it down to the outsides of the light box. When you’re done it should look like this:
Now you can put the black ballast from the clamp light into the hole and thread the aluminum shade (the one that came with the light) back on.
Almost done! Put in the light bulb and plug in the clamp light to test that it works. If it does, we can move on to installing the shade (ie scrap of white fabric).
At this point you have a choice – you can secure the fabric with duct tape like I did or you can use Velcro like The Tip Toe Fairy did. I used duct tape because I don’t think I’ll ever change the light bulb in this baby (LED bulbs last for years). Plus this lamp isn’t anything pretty and I left lots of extra fabric so I could pull off the tape or even cut the fabric off if I really need to. There are pros and cons for both methods!
The fabric helps defuse the light so it isn’t as harsh and spreads over a broad area. Make sure the fabric you choose is clean and stain-free so you don’t have spots of shadow. Even the smallest stains can make noticeable shadows in your photos.. I used an old t-shirt. The front was stained, but not the back! So I cut out a sizeable piece - mine was 20″ x 20″ but you want at least 13″ square so there’s enough fabric to fold around the box opening and secure with duct tape (or with Velcro if you go that route).
Now you can see how the ballast of the clamp light stick out of the box lid. It isn’t a pretty light but it does the job! Here it is in action:
I love the clamp because I can secure it to my kitchen cabinets and change the angle until it’s just right. The light is small enough I can stash it away or just turn the shade around so I don’t splash it while I’m cooking. Things can get crazy in the kitchen!
So that’s how you make a soft light. Do make sure to read The Tip Toe Fairy’s tutorial so you have the background on where I’m coming from for my tutorial. I think it will really help. Unless you like to just wing it, in which case, go for it.
But wait, there’s more! I quickly discovered that the light alone is not enough. I also need a reflector to bounce light around within my shot, otherwise one side of my subject is in dark shadow. A reflector is 1000 times easier than the light box. Here’s how to do it.
DIY Photography Reflector
Here’s what you need:
Here’s what you do:
Well if you’re me the first thing you would have done is photograph the cardboard before wrapping it up in aluminum foil… but this reflector was so easy to make that it was over and done before I thought to get out my camera! Oops! All I have is are photos of the finished product…
Find another piece of scrap cardboard that’s in decent shape. It doesn’t have to be a specific size (mine isn’t even symmetrical!) but ideally the cardboard already has a bend down the middle of it so it can stand up on its own. Tear off a couple sheets of aluminum foil that allow for about an inch of overlap around the sides of the cardboard.
Secure the overlapped edges of the sheets of aluminum foil to the back of the cardboard with any tape – it doesn’t have to be clear because the back won’t face your object. The clear tape is used to secure the sheets of aluminum foil to each other so it looks like one big sheet of aluminum foil.
Here it is standing up:
A reflector can also be something as simple as a white piece of paper. Whatever you can find that will bounce light back unto your subject.
Here are a few test shots!
This one is without the light or reflector, just the lights on in my kitchen. See the harsh shadows and how it seems a little blurry?
Just kitchen lights on
Next I turned off the kitchen lights and turned on the soft light, but I didn’t use the reflector. It looks so much more in focus! The shadows are less harsh but they’re dark.
Just soft light on
And here’s the full set-up with kitchen lights off, soft light on and reflector in use. There’s very soft, light shadows and true color. I took all three of these photos with the exact same camera settings.
Soft light + reflector
Now my pictures are much less frustrating to take because they don’t turn out blurry all the time! I can take one or two pictures instead of 10, trying to get just one that isn’t too blurry. This has cut down on my lunch prep time!
But wait… there’s still one more!
One of the first pictures I took with my new soft light was this:
A loaf of the best gluten-free, egg-free, dairy-free, nut-free bread that I’ve made in the three months that I’ve been trying to make allergy-friendly bread. And I’ll be posting the recipe in just a few days! So go make your soft light and reflector and come back soon to learn more about bread!
